Cutler-Hammer BR2L125RP 125 Amp Main Plug Load Center 4-Circuit Electrical Panel

Highlights:

• Color : Light Grey
• Current Rating : 125 A
• Cable Size : 14 to 1/0 AWG
• Enclosure Material : Metal
• Breaker/ Load Center Type : Main Lug
• Bus Bar Material : Aluminum
• Enclosure Type : NEMA 3R
• Interrupt Rating : 10 kA
• Mounting Type : Surface
• Number of Circuits : 4
• Number of Phases : 1
• Number Of Spaces : 2
• Voltage Rating : 120/240 V
• Wiring Configuration : 3-Wire
• Larger knockout provides easier installation and time savings
• Top or bottom feed, straight-in wiring saves labor and material, one panel for either top or bottom applications
• 2/0 plug easily removable and can be installed in any location on the neutral bar
• Type BR AFCI breakers, compact design for easier wiring and improved wireway access, optional LED indicates one of six trip codes for circuit diagnostics, provides a clean gutter space
• Drywall marking on enclosure – indicates proper mounting depth for flush applications
• Tangential center knockout, easier installation for conduit applications
• Commercial-grade main breaker, 25 kAIC series rated main breaker for great protection
• Neutral bus (strap) is easily removable for sub-panel applications
• Bonding Z-strap provides easy field conversion for service entrance applications
